Structure: 3-Ply Construction, Bonded Core
Fire Rating: Non Fire Rated/20min/45min/60min/90min
Door Thickness: 1 3/8″ or 1 3/4″ for Non Fire Rated Doors, 1 3/4″ for Fire Rated Doors
Core Type: Honeycomb Paper/Particle Board/Mineral Core
Stile and Rail: Wood Stile and Rails for Non Fire Rated, 20min, 45min Fire Rated Doors. Mineral Stile and Rails for 60min, 90min Fire Rated Doors
Crossband: HDF
Finish: TFL (THERMALLY FUSED LAMINATE). Many Standard Color Options, Customized Colors Also Available
Machining: Factory-machined Service Available
Vision Lite/Louver Lite: Allowed, 6″ Minimum Around All Edges
Standards: Meets or Exceeds Industry Standards of ANSI/WDMA I.S. 1A, WI Section 12, AWI Section 1300
Testing Standards: USA NFPA 252 UL 10C, UL 10B, NFPA 252, and CAN/ULC S104, Positive Pressure, Category A Doors, No Additional Edge Sealing System Required
TFL COLOR OPTIONS
Wood Grain
Berin Elm
Zebra
North American Walnut
Bailey
Seine Elm
Mountain Wainut
Ash
Manson
Solid Colors
Milan White
Velvet Grey
Moonlight Grey
Galaxy Grey
Colors and finishes are not limited to what is shown on this page. More options please contact us.
FLUSH DOOR DESIGN OPTIONS
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
